Revolutionizing 3D ToF Sensor with High-Resolution Imaging

$799.00 USD
$999.00 USD

The LiMu 3D LiDAR is a state-of-the-art 3D sensor that seamlessly integrates a QVGA Time-of-Flight (ToF) camera with an RGB camera. Designed to provide accurate, reliable, and cost-effective imaging data, the real-time LiDAR meets the demands for precise depth sensing across a wide range of applications, including industrial automation, automotive, agriculture, and more.

  • QVGA depth pixels provide high-resolution depth sensing
  • High-quality RGB images alongside depth data
  • Robust industrial design built to withstand heavy dust enviroment
  • Real-time data output in 3D point-cloud and RGB images
  • Time-of-Flight 3D technology
SDK

LiMu 3D ToF LiDAR Specifications

1.2.jpg__PID:236e0d0e-7697-4ee4-8e65-70a23a81b193

Depth Pixels

320 x 240

RGB Pixels

2M

Depth Range

11 meters

Depth Field Of View (FoV)

108°x77°

RGB FoV

124°

ToF Ambient Light Resistance

100klux

Frame Rate

30 fps

Data Output

Point-cloud, grayscale, RGB Imgate

Dimensions (ø x L)

11.5 x 7.5 x 5.5 (cm)

Weight

500g

660-module-pic2.jpg__PID:676bd5cb-eb78-4194-bd74-c27dd90364c5

Integrate RGB and Depth Camera in a Compact Form

108° x 77° Wide FoV suitable for Outdoor and Spacious Applications

VSemi_Limu_screenshot.jpg__PID:d5cbeb78-d194-4d74-827d-d90364c5ef1f
660-screenshot-2.jpg__PID:3c684fd1-fbab-4c96-9b67-ecae7c0c2c64

Accurate High-quality Image Synchronization for Detailed Visual Analysis

Successful Story

VSemi partner with JiuFangTaiHe, the top 2 combined harvester OEM in China, to develop 3D intelligent tossing system based on LiMu 3D LiDAR. The advanced, automated solutions designed to accurately control the tossing of corn stalks into the truck bed during havesting, significantly reducing waste and increaseing overall efficienty in operation.  The system is avaliable on the newest model of JiuFangTaiHe's combined harverster in July 2024.

Applications

660-medical_rehibilitation_app.webp__PID:9cdf0d9e-56dd-448c-9f65-4fb37b216828

Medical Rehibilitation

DALL·E 2024-07-07 18.46.02 - A high-tech application interface for volume monitoring in a silo. The interface displays a 3D model of a silo with a cross-sectional view showing the.webp__PID:23d37fcd-815e-436e-8d0e-76974ee48e65

Volume
 Monitoring

Precision Agriculture

DALL·E 2024-07-07 18.47.40 - A realistic scene of a mining tractor or equipment operating in an actual mining environment. The setting includes rocky terrain, large open-pit mines.webp__PID:7fcd815e-236e-4d0e-b697-4ee48e6570a2

Obstacle
Avoidance

660-medical_rehibilitation_app.webp__PID:9cdf0d9e-56dd-448c-9f65-4fb37b216828

Medical Rehibilitation
